90 degree right angle reducer

We have exported our products to clients around the world and earned a good reputation because of our superior product quality and after-sales service.
We warmly welcome customers both at home and abroad to contact us to negotiate business, exchange information and cooperate with us.

Category:

Description

Quick Details
Place of Origin:
Zhejiang, China
Brand Name:
Redsun
Gearing Arrangement:
Bevel / Miter
Output Torque:
N/A
Input Speed:
10~1450rpm
Output Speed:
As per Ratio
Applicable Industries:
Manufacturing Plant, Food & Beverage Factory, Farms, Construction works , Energy & Mining
Ratio:
1:1, 1.5:1, 2:1, 2.5:1, 3:1, 4:1, 5:1
Supply Ability
Supply Ability:
70000 Set/Sets per Year
Packaging & Delivery
Packaging Details
Plywood case
Port
NINGBO/SHANGHAI/GUANGZHOU/XIAMEN
Lead Time :
Quantity(Sets) 1 – 100 >100
Est. Time(days) 30 To be negotiated
Product Description

Features.

◆ Standard and various, ratio 1:1,1.5:1,2:1,3:1, all are exact ratio.
◆ When the ratio is not 1:1 and pinion shaft is input, so cross shaft is reduced output. When cross shaft is input, the pinion shaft is increased output.
◆ Spiral bevel gear, stable transmission, low noise level, small vibration and strong loading capacity.
◆ Double input shaft is available.
◆ Multiple output shaft is available.
◆ Any mounting position is available.

Main applied for

◆ Agriculture and food
◆ Building and construction
◆ Forest and paper
◆ Metal processing
◆ Chemical industry and environmental protection

Housing material
Cast iron/Ductile iron
Housing hardness
Stainless steel
Gear material
20CrMnTi alloy steel
Surface hardness of gears
HRC58~62
Gear core hardness
HRC33~40
Input / Output shaft material
42CrMo alloy steel
Input / Output shaft hardness
HRC25~30
Machining precision of gears
Accurate grinding, 6~5 Grade
Lubricating oil
GB L-CKC220-460, Shell Omala220-460
Heat treatment
tempering, cementiting, quenching, etc.
Efficiency
98%
Noise (MAX)
60~68dB
Vibration
≤20µm
Backlash
≤20Arcmin
Brand of bearings
China top brand bearing, HRB/LYC/ZWZ/C&U. Or other brands requested, SKF, FAG, INA, NSK.
Brand of oil seal
NAK — Taiwan or other brands requested

As one of the leading gearboxes agricultural manufacturers, mechanical product suppliers and exporters, we supply gearboxes agricultural and many other products for cluster gearboxes agricultural. gearboxes agricultural, constant velocity ouplings Manufacturer, gearboxes agricultural Supplier, gearboxes agricultural Exporter, gearboxes agricultural Seller, gearboxes agricultural Made In China, Wholesale gearboxes agricultural, Buy gearboxes agricultural, Customize gearboxes agricultural – Find gearboxes agricultural Manufacturers and Suppliers. Choose from quality driveshaft manufacturers, suppliers and exporters on gearboxesagricultural.com.
